More Specification
| Body Materials | Body materials: 316 Stainless steel, machined interiorand electropolished exterior finish |
|---|---|
| Bearing Housing | Epoxy coated cast iron |
| Impeller | 3A Food Grade Neoprene or EPDM |
| Seal | Carbon/Ceramic machanical type, Optional: Tungsten Carbide/Ceramic hard faced mechanical seal or Tungsten Carbide / Ceramic hard faced flushed seal |
| Seal Elastomer | Food grade Nitrile |
| Bearings | Twin single row, ball type |
| Shaft material | 316 Stainless steel |
| Port Type | 1” Tri-Clamp 28300-1xxx 25mm IDF/ISS 28300-3xxx 1” RJT to BS1864 28300-4xxx |
| Weight | 4.4 (kg) 9.7(Ib) |
